DX05型 活塞环湿式自动修口机床

Number of visits: Date:2019-12-18

用途及特点
  活塞环湿式自动修口机床是集国内外同类机床之优点,采用台湾式修口套重新设计的高效率、高精度、自动化的活塞环修口机床。该机床以湿式修口为基础,特别适合钢质环、球铁环修口,也可用于干修口(合金铸铁环)。该机床采用意大利康茂胜气油复合缸使压料动作更加快速平稳;采用日本三菱产PLC 控制,动作可靠。加工环径范围大,磁性分离,深受客户欢迎。

USES and features

DX05 piston ring type wet mouth machine automatically.Piston ring mouth wet automatic repair machine is with the advantages of the similar machine tools at home and abroad, use of words set of Taiwan to design high efficiency, high precision and automation of the piston ring repair machine. The machine tool based on the wet words, especially suitable for steel ring, ball hoop mouth, can also be used to dry mouth (alloy cast iron ring). The machine adopts the Italian Kang Maosheng gas-oil composite cylinder pressure feeding smooth action more quickly; USES the Japanese mitsubishi PLC control, reliable operation. Processing large range ring diameter, magnetic separation, are very popular with customers.



加工活塞环直径范围

Machining piston ring diameter range

Φ 38mm- Φ 150mm (A 型)Φ 100mm- Φ 280mm (B 型)

Φ 38 mm - 150 mm (A type  ) Φ Φ 100 mm - 280 mm ( B type  ) Φ

磨头转速

Grinding head rotation speed

5600r/min

磨头电机

The grinding head motor

功率0.75KW 转速2800r/min

power0.75KW  speed 2800r/min

生产效率

The production efficiency

6-8 循环/min

6-8 cycle /min

金刚石砂轮

Diamond grinding wheel

Φ 150mm × Φ 22mm Φ 120mm × Φ 22mm

机床总功率

The machine total power

1.55KW

机床外形尺寸

Machine tool shape dimension

长×宽×高≈ 2110mm × 880mm × 1780mm

Long * wide * high≈2110mm×880mm×1780mm

机床重量(净重 )

Machine weight (net weight)

约750 kg

about750kg
